WindowsLDP Description
WindowsLDP (Load Distribution Program), is a quasi-static tool for designing and analysing external and internal spur and/or helical pairs of gears. Most members of the consortium have used this software program extensively as their main tool for analysis and gear design. There are several versions of this model that can perform surface wear and duty-cycle analyses. WindowsLDP uses semi-analytical formulations that are computationally efficient and precise to calculate the load distribution between multiple teeth of gears. It uses the predicted load distribution to compute the loaded transmission error, root stress distributions, contact stress distributions and mesh stiffness functions. Other design relative parameters, such as surface temperature and lubricant film thickness, are also calculated. The user can choose to use SI or English units for the analyses. WindowsLDP also offers multi-torque analysis and manufacturing robustness analyses.
WindowsLDP Alternatives
Ansys Motor-CAD
Ansys MotorCAD is a dedicated tool for electric machine design. It allows you to quickly simulate multiphysics across the entire torque-speed operating range. Motor-CAD allows engineers to evaluate motor topologies across the entire operating range. This allows them to create designs that are optimized for size, efficiency, and performance. Motor-CAD software's four modules, Emag, Therm Lab, Mech, allow multiphysics calculations to be performed quickly, iteratively, and users can move from concept to final design in a shorter time. Motor-CAD users can explore more motor topologies and fully evaluate the impact of advanced loss effects during the initial stages of an electrical mechanical design with Motor-CAD's streamlined data input process. This release features powerful new features for design optimization and multi-physics analysis, as well as system modeling for electric motors. Multiphysics simulations are fast across the entire torque-speed range.
Learn more
DC-E DigitalClone for Engineering
DigitalClone®, for Engineering is the only software that integrates multiple scales of analysis into a single package. It is the world's best gearbox reliability prediction tool. DC-E, in addition to the modeling and analysis capabilities at the level of the gearbox and the gear/bearing, is the only software that models fatigue life using detailed, physics-based models (US Patent 10474772B2).
DC-E allows the construction of a digital twin of a gearbox. This includes all stages of the asset's lifecycle, from design and manufacturing optimization to supplier selection to failure root cause analysis to condition based maintenance and prognostics. This computational environment reduces the time and cost of bringing new designs to market and maintaining them over time.
Learn more
SkyCiv Structural 3D
SkyCiv Structural 3D, a cloud-based Structural Analysis program, allows users to design, analyze, and model complex 3D structures. It can be used online and does not require installation. SkyCiv Structural 3D is the best online structural analysis. It includes the following: – Powerful Analysis: Linear and P-Delta Cables, Buckling Plates, Frequency RS - Integrated design checks for steel, wood connections, foundations wind (AISC. NSD. AISI. EN. AS. CSA. BS plus more ...)
Learn more
SABR
SABR is a well-known package for shaft, gear, and bearing design. SABR was designed to integrate into product development and reduce time. It provides an intuitive graphical interface that allows the transmission system to model at a level appropriate to the current design phase. It also allows for sensitivity studies that allow you to quickly determine the effects on different geometric features, bearing types, and gear positions. The solvers are based on Ricardo's product design and manufacturing experience. They are constantly updated to keep them in line with real-world testing and development programmes. A simple and intuitive interface allows for rapid and accurate model building. Bearing analysis including life calculation and stress plots accounting to loading and misalignment. Duty cycles with complex load paths and multiple loads. Bevel, epicyclic, and parallel gears.
Learn more
